Bridge & Material Handling Cranes
Leading Manufacturers and Wholesaler of Double Girder Material Handling Crane, Factory Duty Single Girder Bridge Crane, Heavy Industrial Double Beam Bridge Crane, Heavy-Duty Bridge Material Handling Crane, Industrial Bridge Girder Crane and Industrial Double Girder Bridge Crane from Ahmedabad.
| Business Type | Manufacturer, Supplier |
| Power Source | Electric |
| Maximum Lifting Capacity | 30 Ton |
| Crane Type | Double Girder Material Handling Crane |
| Girder Configuration | Double Girder |
| Bridge Span Length | 30 Meter |
| Maximum Lifting Height | 15 Meter |
| Bridge Travel Speed | 15 M/min |
| Hoisting Mechanism | Electric Wire Rope Hoist |
| Control System | Pendant Push Button / Wireless Radio Remote |
| Operating Voltage | 415 Volt AC, 3 Phase |
| Operating Frequency | 50 Hz |
| Duty Classification | M5 Heavy-Duty Industrial |
| Structure Material | Heavy-Duty Mild Steel Fabrication |
| Surface Finish | Industrial Grade Anti-Corrosive Powder Coated Finish |
| Usage Application | Heavy Material Handling In Steel Plants, Engineering Workshops, Manufacturing Units, Warehouses & Industrial Facilities |
| Business Type | Manufacturer, Supplier |
| Crane Type | Single Girder EOT Crane |
| Power Source | Electric |
| Rated Lifting Capacity | 5 Ton |
| Girder Configuration | Single Girder |
| Bridge Span Length | 10–20 Meter |
| Maximum Lifting Height | 6 Meter |
| Hoisting Speed | 4 M/min |
| Hoisting Mechanism | Electric Wire Rope Hoist |
| Operating Voltage | 415 Volt AC, 3 Phase |
| Operating Frequency | 50 Hz |
| Duty Classification | Class II |
| Control System | Pendant Push Button / Wireless Radio Remote |
| Structure Material | Heavy-Duty Mild Steel Fabrication |
| Surface Finish | Industrial Grade Anti-Corrosive Paint Coating |
| Usage Application | Manufacturing Plants, Warehouses, Engineering Workshops, Fabrication Units & Industrial Material Handling |
| Business Type | Manufacturer, Supplier |
| Maximum Lifting Capacity | 25 Ton |
| Crane Type | Double Girder EOT Crane |
| Girder Configuration | Double Girder |
| Hoisting Mechanism | Electric Wire Rope Hoist |
| Power Source | Electric |
| Bridge Span Length | Customizable As Per Requirement |
| Maximum Lifting Height | Up To 12 Meter |
| Crane Travel Speed | 10–15 M/min |
| Hoisting Speed | 2–3 M/min |
| Operating Voltage | 415 Volt AC, 3 Phase |
| Operating Frequency | 50 Hz |
| Control System | Pendant Push Button / Wireless Radio Remote |
| Duty Classification | M5 Heavy-Duty Industrial |
| Structure Material | Heavy-Duty Mild Steel Fabrication |
| Usage Application | Steel Plants, Heavy Engineering Units, Manufacturing Facilities, Warehouses, Fabrication Workshops & Industrial Material Handling Systems |
| Business Type | Manufacturer, Supplier |
| Power Source | Electric |
| Maximum Lifting Capacity | Up To 50 Ton |
| Crane Type | Single & Double Girder Overhead Crane |
| Girder Configuration | Single / Double Girder |
| Bridge Span Length | Up To 30 Meter |
| Maximum Lifting Height | Up To 20 Meter |
| Maximum Travel Speed | 12–15 M/min |
| Hoisting Mechanism | Electric Wire Rope Hoist |
| Bridge Travel System | Motorized End Carriage Drive |
| Cross Travel Mechanism | Motorized Trolley Travel |
| Control System | Pendant Push Button / Wireless Radio Remote |
| Operating Voltage | 415 Volt AC, 3 Phase |
| Operating Frequency | 50 Hz |
| Structure Material | Heavy-Duty Mild Steel Fabrication |
| Usage Application | Material Handling In Steel Plants, Manufacturing Units, Engineering Workshops, Warehouses & Heavy Industrial Facilities |
| Business Type | Manufacturer, Supplier |
| Type | Crane Bridge Girder |
| Country of Origin | Made In India |
| Application | Manufacturing Plants, Steel Industries, Warehouses, Engineering Workshops, Fabrication Units & Heavy Material Handling Applications |
| Girder Configuration | Double Girder |
| Construction Material | Heavy-Duty Structural Mild Steel |
| Manufacturing Process | Precision Welded Fabrication |
| Surface Finish | Industrial Grade Anti-Corrosive Paint Coating |
| Load Compatibility | Suitable For 5–50 Ton Crane Systems |
| Bridge Span | Customizable As Per Requirement |
| Installation Type | Overhead Bridge Crane Assembly |
| Power Compatibility | Suitable For Electric EOT & Gantry Cranes |
| Operating Duty | M5 / M6 Heavy Industrial Duty |
| Corrosion Resistance | Yes |
| Application Area | Gantry Crane & Overhead Crane Systems |
| Customization Available | Yes |
| Business Type | Manufacturer, Supplier |
| Crane Type | Overhead Traveling EOT Crane |
| Power Source | Electric |
| Maximum Lifting Capacity | 5 Ton |
| Girder Configuration | Double Girder |
| Hoisting Mechanism | Electric Wire Rope Hoist |
| Hoist Traveling Speed | 5–10 M/min |
| Crane Traveling Speed | 10–15 M/min |
| Bridge Span | Customizable As Per Requirement |
| Maximum Lifting Height | Up To 12 Meter |
| Operating Voltage | 415 Volt AC, 3 Phase |
| Operating Frequency | 50 Hz |
| Control System | Pendant Push Button / Wireless Radio Remote |
| Duty Classification | M5 Heavy Duty |
| Structure Material | Heavy-Duty Mild Steel Fabrication |
| Usage Application | Steel Plants, Warehouses, Engineering Workshops, Manufacturing Units & Heavy Material Handling Industries |
